Laser Printer

Product Description

Laser Printer

Feature:

* Small in size with the integrated touch screen

* High speed flying marking system

* Raster font, vector font for choosing

* No limiting characters in the working area

* Economical and low maintenance cost

We import advanced foreign technical and parts to keep the machine’s competitiveness. Such as generating laser and the lens, which can meet almost marking need. The machine is small size so it takes small space. Widely used in food& beverage ,medicine cosmetics industry and garment industry.

2. Technical Parameter

This machine is made of generator laser, lens, photoelectric sensor, main controller board and power.

it can marking under flying status, and can count it when working. Raster font, vector font for choosing. Can non-stopping working for 24 hours.

Products:

1
Model Item  Type LS
Machine general machine Machine material Aluminum structures
Generator laser Enclosed metal for CO2 laser generator
Output power ≥30W
Laser wave length 10.2um
Lens High precision 2 dimensional scanning system
Marking speed ≤12000mm/s
Main control system Highly integrated motherboard, embedded 7 inch screen
Operating system WIN CE
Cooling system wind
Laser markingparameter Focus zoom lens focal length  130mm
Marking line type Raster font, vector font for choosing
Min.line width 0.03mm
Repeatability accuracy 0.01mm
Working area 90mm×90mm or other
Positioning Red light positioning and focusing
Lines of marking No limited in working area
Speed 0~100m/min (depends on the material)
Supporting language Fonts Chinese and English, Numbers, such as traditional Chinese standard repertoire
File BMP/DXF/HPGL/JPEG/PLT
Code CODE39、CODE128、CODE126、QR

Other
Power 220V
Power Consumption 900W
Net weight 25kg
Size 730mmX137mmX192mm
Working  environment The external temperature 0 ℃ – 45 ℃; Humidity of 95% or less; The condensation; No vibration
